NİCOLAS CORREA-FOX M-125 (5E KÖPRÜ TİPİ)
-
SHW-POWER SPEED 1600 (6E BORWERK)
-
WELE-HB 1620-130 (4E BORWERK)
-
WELE-LB425Z KÖPRÜ TİPİ İŞLEM MERKEZİ
-
EVERRİCHO-ER-LB-4270 KÖPRÜ TİPİ İŞLEME MERKEZİ
-
EVERRİCHO-ER-LB-3216 KÖPRÜ TİPİ İŞLEME MERKEZİ
-
MAZAK-FH-8800 YATAY İŞLEME MERKEZİ
-
DMG MORI-NHC 5000 YATAY İŞLEME MERKEZİ
-
DMG MORI-CMX 70U 5 EKSEN İŞLEME MERKEZİ
-
WELE-AA 1565 C TİPİ DİKEY İŞLEM MERKEZİ (3 ADET)
-
WELE-VQ 1060 C TİPİ DİKEY İŞLEM MERKEZİ
-
SUNMILE-JMV 1100 C TİPİ DİKEY İŞLEME MERKEZİ
-
TOPTURN-S36XL CNC TORNA
-
TAKISAWA-NEX-110 H7 CNC TORNA
-
SN71 ÇAP 710 mm BOY 4.000 mm UNIVERSAL TORNA
-
SN51 ÇAP 510 mm BOY 2.000 mm UNIVERSAL TORNA
-
ARION-KALIPÇI MANUEL FREZE
-
KESMAK-ÇAP 320 MM ŞERİT TESTERE (AÇILI KESİM)
-
KESMAK-ÇAP 350 MM ŞERİT TESTERE (SERVO KONT.)
-
CNC ABKANT BÜKÜM 300 TON C TİPİ MANUEL 5 TON KAYNAK POZİSYONER (3 ADET)
-
KOLARC 500 AMPER MANUEL KAYNAK MAKİNALARI (30 ADET)
-
FANUC MATE110ID KAYNAK ROBOTU 500 A (LİNCOLN) ve L TİPİ POZİSYONER
-
FANUC MATE110ID KAYNAK ROBOTU 500 A (FRONIUS) ve SLİDER TİPİ POZİSYONER
-
FANUC MATE110ID KAYNAK ROBOTU 700 A (LİNCOLN) ve T TİPİ POZİSYONER
-
FANUC MATE110ID KAYNAK ROBOTU 500 A (FRONIUS) ve SLİDER TİPİ VE L TİPİ POZİSYONER (X2 İSTASYON)
-
RAYCUS-LAZER KAYNAK MAKİNESİ- 1.5 KW
Bazı tezgahlarımızın açıklamaları aşağıdaki gibidir;
NİCOLAS CORREA FOX M-125; (5 AXİS SİM.)
- LONGITUDINAL TRAVERSE X = 12,500 mm
- VERTICAL TRAVERSE Z = 1,750 mm
- CROSS TRAVERSE Y = 5,000 mm |
DISTANCE BETWEEN COLUMNS = 4,250 mm - VERTICAL CAPACITY D | MACHINE ABOVE FLOOR LEVEL |DISTANCE CROSSBEAM- TABLE: 2,850 mm
—————————————————————————————————————————————————————-
- SPINDLE MOTOR 52 kW (S1-100%) – 1,375 Nm – 6,000 rpm (water cooled)
- CNC HEIDENHAIN TNC 640
- ADAPTATIVE FEED CONTROL AFC | “CORREA” CYCLE
—————————————————————————————————————————————————————-MILLING HEAD CAC 2 | MAGAZINE ON COLUMN | 2 AUTOMATIC HEAD CHANGER
- 1st DETACHABLE HEAD OAD | AUTOMATIC ORTHOGONAL HEAD (6.000 rpm / 0.02º x 0.02º)
- 2nd DETACHABLE HEAD AL-600 | LONG RIGHT ANGLE HEAD (1.500 rpm – 25 kW – 800 Nm)
STORED IN A REMOVABLE HEAD SUPPORT ON THE TABLE TO PICK IT UP
- 3rd DETACHABLE HEAD E5E (15.000 rpm- 45 kW- 120 Nm) | 2 CONTINUOUS AXES HEAD
KINEMATIC FUNCTION FOR E5E CONTINUOUS 2 AXES HEAD
SPARE ELECTROSPINDLE ELECTROSPINDLE KESSLER | 15.000 rpm- 45 kW- 120 Nm – HSK100
SHW POWER SPEED 5
- TRAVELS OF THE MACHINES
X AXİS : 8000 mm
Y AXİS : 1600 mm
Z AXİS : 1300 mm - SEPARATE CNC ROTARY TABLE (B AXIS)
CLAMPING SURFACE 1600 mm
LOAD CAPACITY 7000 KG
DIVIDING ACCURACY 6 arc seconds - CNC HEIDENHAIN TNC 530
- AUTOMATIC HEAD
C AXIS INDEXED AUTOMATİCALLY 360DEG*1DEG
A AXIS INDEXED AUTOMATİCALLY 180DEG*1DEG
WELE HB 1620-130 BORWERK;
- TRAVELS OF THE MACHINES
X:3.000 Y:2.100 Z:1.500 MM W:700 MM
ROTARY TABLE 1650 mm
DMG MORI NHC5000 YATAY İŞLEME MERKEZİ
- Mitsubishi_M730BM
- Travel X/Y/Z: 730/730/880 mm
- Pallet size: 500×500 mm
- High-output Spindle 30/ 18.5 kW, 15,000 min-1
- Max. workpiece swing diameter mm (in.) 800
- Max. workpiece height mm (in.) 1,000
- 3D-control HEIDENHAIN TNC 620
- Axes travel:
X / Y / Z – 750 / 600 / 520 mm
Range of travel of the rotary axes B = -10o/+95o
C = n x 360o - Distance spindle nose to Table: 160 – 680 mm
- Clamping area: Ø800 with curtailment to 620 mm
- 9 T-slots (14 H7), distance between slots 63 mm
- Max. table load: 350 kg
- Speed range: 20 to 12.000 rpm
- Spindle power: 13 kW (40% DC)
- 9 kW (100% DC)
- Torque: 83 Nm (40% DC)
- 57 Nm (100% DC)
WELE AA 1565 C TİPİ DİKEY İŞLEM MERKEZİ
(4+1 AXIS)
WELE VQ 1060 C TİPİ DİKEY İŞLEM MERKEZİ
- TRAVELS OF THE MACHINES
X: 1.500mm Y:650 Z:600 A axis: Ø400 mm_6000rpm (AA1565)
X: 1000mm Y:600 Z:500 A axis: Ø300 mm_10000rpm(VQ1060)
MAZAK FH-8800 YATAY İŞLEME MERKEZİ
- TRAVELS OF THE MACHINES
X: 1.300mm Y:1100 Z:1000
A axis: 0.001° indexing, 360.000 positions - MILLING SPINDLE
motor output: 30 Kw max., spindle speed 7.000 rpm max. torque: 1.177 Nm, 2 step gearbox - PALLET CHANGER
2 pallets, pallet size: 800 x 800 mm
HAIMER TAKIM ÖLÇME UNO 20170
Takımların boyları ve çapları makinede ölçülerek cnc tezgahlara aktarılmaktadır.
CMM ÖLÇÜM CİHAZI
SARF DOLABI
FANUC MATE110ID KAYNAK ROBOTU 500 A ve Slider Tipi Pozisyoner
